LED Single-Mode Fiber Extender

Enhance your network connectivity with the LED Single-Mode Fiber Extender, designed for high-speed, long-distance optical fiber transmission. Supporting single-mode dual-core optical fiber with an LC interface, this extender provides seamless data communication over distances up to 1500 meters.

Key Features:

• High-Speed Transmission – Supports single-mode fiber transmission up to 1.5 km
• Plug & Play – No driver required, works immediately after connection
• LED Indicators – Power, FX/ACT, TP/ACT, and Data indicators for easy monitoring
• Reliable Connectivity – Features one cable interface & one fiber interface
• Power Supply – 100~240V AC, 50/60Hz input voltage

Technical Specifications:

• Model: EOC410

• Fiber Type: Single-mode dual-core with LC interface

• DC Output Voltage: 5V, 5A
• Current Consumption: Max. 0.7A
• Operating Conditions: Standard industrial environment
• LED Indicators:
  • Power – Indicates device is powered on
  • FX/ACT – Shows fiber communication status
  • TP/ACT – Shows network cable status
  • Data – Indicates active data transmission

**This is a certified recondition product and may have minor cosmetic imperfections. All laser illumination projectors have been used and do not offer full illumination performance.
